4K Quad-Display KVM over IP Multi-View Receiver
Model KE8980MRPart no. KE8980MR-AX-GEAN 4710469349867
49 specifications
- Weight1.34 kg
- ColourBlack
- Number of computers controlled4
- Ethernet LANYes
- HD type4K Ultra HD
- Built-in displayNo
Overview
- Weight
- 1.34 kg
- Colour
- Black
- Number of computers controlled
- 4
- Ethernet LAN
- Yes
- HD type
- 4K Ultra HD
- Built-in display
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- KE8980MR
- Part number
- KE8980MR-AX-G
- EAN / UPC
- 4710469349867
- Also known as
- ATEN 4K Quad-Display KVM over IP Multi-View Receiver
Specifications
49 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI/DisplayPort |
| Console ports | DisplayPort, HDMI |
| Console DisplayPorts ports quantity | 2 |
| Console HDMI ports quantity | 2 |
| USB hub | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| Serial port type | RS-232 |
| Serial ports quantity | 1 |
| Audio connections | Yes |
| Headphone outputs | 1 |
| Number of microphone inputs | 1 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Power, Reset |
| Hot keys | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Output voltage | 19 V |
| External power adapter | Yes |
| Power consumption (typical) | 33 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 190 mm |
| Depth | 200 mm |
| Height | 41.8 mm |
| Weight | 1.34 kg |
Packaging data
| Specification | Value |
|---|---|
| Package volume | 11723.174 cm³ |
| Package weight | 2.31 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| AC adapter included | Yes |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84718000 |
| Master (outer) case net weight | 5.7 kg |
| Master (outer) case width | 365 mm |
| Master (outer) case length | 396 mm |
| Master (outer) case height | 294 mm |
| Master (outer) case gross weight | 7.6 kg |
| Master (outer) case volume | 42503.587 cm³ |
| Country of origin | Taiwan |
