4K Quad Display KVM over IP Console Station
Model KA8585-AX-GEAN 4711581521964
31 specifications
- Weight1.34 kg
- ColourBlack, Grey
- Console USB ports quantity4
- Ethernet LANYes
- HD type4K Ultra HD
- Rack mountingNo
Overview
- Weight
- 1.34 kg
- Colour
- Black, Grey
- Console USB ports quantity
- 4
- Ethernet LAN
- Yes
- HD type
- 4K Ultra HD
- Rack mounting
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- KA8585-AX-G
- Part number
- KA8585-AX-G
- EAN / UPC
- 4711581521964
- Also known as
- ATEN 4K Quad Display KVM over IP Console Station
Specifications
31 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Console USB ports quantity | 4 |
| Console ports | USB A, DisplayPort, HDMI, 3.5mm headphone, RJ–45 |
| Console DisplayPorts ports quantity | 2 |
| Console HDMI ports quantity | 2 |
| Console RJ-45 ports quantity | 2 |
| USB connector type | Mini-USB A |
| Serial port type | DE-9 (DB-9) |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 60 Hz |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black, Grey |
| LED indicators | Yes |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 19 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 190 mm |
| Depth | 200 mm |
| Height | 41.8 mm |
| Weight | 1.34 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84718000 |
| Country of origin | Taiwan |
