ATEN 2-Port USB 4K HDMI Dual-Display KVMP Switch (Cables included)
ATEN

2-Port USB 4K HDMI Dual-Display KVMP Switch (Cables included)

Model CS742HPart no. CS742H-AT-UEAN 4710469349874

55 specifications
  • Weight1.21 kg
  • ColourBlack
  • Number of computers controlled2
  • HD typeDual QHD
  • Built-in displayNo
  • Power sourceDC
See all specifications

Overview

Weight
1.21 kg
Colour
Black
Number of computers controlled
2
HD type
Dual QHD
Built-in display
No
Power source
DC
Brand
ATEN
Category
KVM Switch
Model
CS742H
Part numbers
CS742H-AT-U, CS742H-AT-G
EAN / UPC
4710469349874
Also known as
ATEN 2-Port USB 4K HDMI Dual-Display KVMP Switch (Cables included)

Specifications

55 specifications in 11 groups

Ports & interfaces

Number of computers controlled2
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
HDMI ports quantity4
USB 2.0 Type-B ports quantity2
Console USB ports quantity2
Console portsHDMI, USB A, 3.5mm headphone
Console HDMI ports quantity2
USB hubYes
USB 2.0 Type-A hub ports quantity2
DC-in jackYes

Performance

HD typeDual QHD
Maximum resolution5120 x 1440 pixels
Scan interval1,3,4,5,8,10,15,20,25,30,35,40,45,50,55,60,70,80,90,99 s
Hot-Plug supportYes
Plug and PlayYes
Firmware upgradeableYes

Design

Product colourBlack
Housing materialMetal, Plastic
LED indicatorsYes
Push buttonYes
Hot keysYes

Display

Built-in displayNo

Power

Power sourceDC
Input voltage5 V
Power consumption (typical)3.63 W

System requirements

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac operating systems supportedYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width81.7 mm
Depth202.3 mm
Height25 mm
Weight1.21 kg

Packaging data

Package width95 mm
Package depth265 mm
Package height220 mm
Package volume5550.101932032 cm³
Package weight1.33 kg

Packaging content

Cables includedHDMI, USB Type-A to USB Type-B
AC adapter includedYes
ManualYes
Remote control includedYes
Rubber feetYes

Logistics data

Harmonized System (HS) code84718000
Master (outer) case net weight6.05 kg
Master (outer) case width232 mm
Master (outer) case length500 mm
Master (outer) case height283 mm
Master (outer) case gross weight7.53 kg
Master (outer) case volume32819.225200128 cm³
Country of originThailand
