4-Port USB 3.0 8K DisplayPort Dual-Display KVMP™ Switch (Cables included)
Model CS1944DPA-AT-GEAN 672792016868
40 specifications
- Weight620 g
- ColourBlack
- Number of computers controlled4
- HD type8K Ultra HD
- Rack mountingNo
- Power sourceDC
Overview
- Weight
- 620 g
- Colour
- Black
- Number of computers controlled
- 4
- HD type
- 8K Ultra HD
- Rack mounting
- No
- Power source
- DC
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS1944DPA-AT-G
- Part number
- CS1944DPA-AT-G
- EAN / UPC
- 672792016868, 4711581520554, 5715328298309
- Also known as
- ATEN 4-Port USB 3.0 8K DisplayPort Dual-Display KVMP™ Switch (Cables included)
Specifications
40 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 8 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 4 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, DisplayPort, USB A |
| Console DisplayPorts ports quantity | 1 |
| Console RJ-45 ports quantity | 1 |
| USB hub | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 4 |
| USB connector type | USB Type-A, USB Type-B |
| Headphone outputs | 6 |
| Number of microphone inputs | 6 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | 8K Ultra HD |
| Maximum resolution | 7680 x 4320 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,99 s |
| Maximum refresh rate | 240 Hz |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| LED indicators | Yes |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 12 V |
| Power consumption (typical) | 3.18 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 71.8 mm |
| Depth | 260 mm |
| Height | 43 mm |
| Weight | 620 g |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84718000 |
| Country of origin | Taiwan |
