ATEN CS1914 KVM switch Black, Grey
Model CS1914EAN 672792007095
39 specifications
- Weight910 g
- ColourBlack, Grey
- Number of computers controlled4
- Maximum resolution3840 x 2160 pixels
- Rack mountingNo
- Output voltage5 V
Overview
- Weight
- 910 g
- Colour
- Black, Grey
- Number of computers controlled
- 4
- Maximum resolution
- 3840 x 2160 pixels
- Rack mounting
- No
- Output voltage
- 5 V
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS1914
- Part number
- CS1914
- EAN / UPC
- 672792007095
- Also known as
- ATEN CS1914 KVM switch Black, Grey
Specifications
39 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| Console USB ports quantity | 2 |
| Console ports | USB A |
| USB hub | Yes |
| USB connector type | USB Type-A, USB Type-B |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Audio connections | Yes |
| Headphone outputs | 6 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 3840 x 2160 pixels |
| Automatic switching | Yes |
| Scan interval | 1,5,99 s |
| HDCP | Yes |
| Hot-Plug support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black, Grey |
| Housing material | Metal, Plastic |
| LED indicators | Status, USB |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Output voltage | 5 V |
| External power adapter | Yes |
| Power consumption (typical) | 3.3 W |
System requirements
| Specification | Value |
|---|---|
| Mac operating systems supported | Yes |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 88 mm |
| Depth | 270 mm |
| Height | 55.5 mm |
| Weight | 910 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Audio (3.5mm), DisplayPort, USB |
| AC adapter included | Yes |
| Manual | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176200 |
