ATEN CS1798 KVM switch Rack mounting Black

ATEN CS1798 KVM switch Rack mounting Black

Model CS1798EAN 672792005565

49 specifications
  • Weight3.49 kg
  • ColourBlack
  • Number of computers controlled512
  • HD typeWUXGA
  • Rack capacity1U
  • Built-in displayNo
See all specifications

Overview

Weight
3.49 kg
Colour
Black
Number of computers controlled
512
HD type
WUXGA
Rack capacity
1U
Built-in display
No
Brand
ATEN
Category
KVM Switch
Model
CS1798
Part number
CS1798
EAN / UPC
672792005565, 3701007123637, 6727920055654
Also known as
ATEN CS1798 KVM switch Rack mounting Black

Specifications

49 specifications in 10 groups

Ports & interfaces

Number of computers controlled512
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
HDMI ports quantity9
Console USB ports quantity2
Console ports3.5mm headphone, HDMI, USB B
USB hubYes
USB connector typeUSB Type-B
USB version2.0
Audio connectionsYes
Headphone outputs8
DC-in jackYes

Performance

HD typeWUXGA
Maximum resolution1920 x 1200 pixels
Video bandwidth60 Hz
HDCPYes
Hot-Plug supportYes
Firmware upgradeableYes

Design

Rack capacity1U
Rack mountingYes
Product colourBlack
Housing materialMetal
CascadableYes
LED indicatorsYes
Push buttonYes
Hot keysYes
Keyboard languageChinese Traditional, English, French, German, Greek, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish, Swiss, UK English, US English

Display

Built-in displayNo
On Screen Display (OSD)Yes

Power

Power sourceDC
Input voltage5 V
Power consumption (typical)12 W

System requirements

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac operating systems supportedYes
Other operating systems supportedYes

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width432.4 mm
Depth257.2 mm
Height44 mm
Weight3.49 kg

Packaging content

Cables includedKVM
AC adapter includedYes
Quick installation guideYes
Rack mount kitYes

Logistics data

Harmonized System (HS) code85176200
