ATEN CS1794 KVM switch Rack mounting Black, Stainless steel

ATEN CS1794 KVM switch Rack mounting Black, Stainless steel

Model CS1794EAN 6727921002602

43 specifications
  • Weight530 g
  • ColourBlack, Stainless steel
  • Number of computers controlled4
  • HD typeWUXGA
  • Rack capacity1U
  • Built-in displayNo
See all specifications

Overview

Weight
530 g
Colour
Black, Stainless steel
Number of computers controlled
4
HD type
WUXGA
Rack capacity
1U
Built-in display
No
Brand
ATEN
Category
KVM Switch
Model
CS1794
Part number
CS1794
EAN / UPC
6727921002602, 163121389833, 672792100260, 999992485509 +2 more
Also known as
ATEN CS1794 KVM switch Rack mounting Black, Stainless steel

Specifications

43 specifications in 10 groups

Ports & interfaces

Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
HDMI ports quantity5
Console USB ports quantity2
Console ports3.5mm headphone, 3.5mm mic, HDMI, USB A
USB 2.0 ports quantity4
USB connector typeUSB Type-A, USB Type-B
Audio connectionsYes
Headphone outputs6
Number of microphone inputs6
DC-in jackYes

Performance

HD typeWUXGA
Maximum resolution1920 x 1200 pixels
Scan interval1,99 s
HDCPYes
Power on detectionYes
Firmware upgradeableYes

Design

Rack capacity1U
Rack mountingYes
Product colourBlack, Stainless steel
Housing materialMetal, Plastic
LED indicatorsYes
Push buttonYes
Hot keysYes

Display

Built-in displayNo
On Screen Display (OSD)No

Power

Power sourceDC
Input voltage5.3 V
Power consumption (typical)4.8 W

System requirements

Windows operating systems supportedYes
Linux operating systems supportedYes
Mac operating systems supportedYes

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width262.3 mm
Depth76.8 mm
Height44 mm
Weight530 g

Logistics data

Harmonized System (HS) code85176200
