16-Port USB - HDMI KVM Switch with USB Peripheral port
Model CS17916-AT-GEAN 4719264641602
45 specifications
- Weight5.1 kg
- ColourBlack
- Number of computers controlled16
- HD typeWUXGA
- Built-in displayNo
- Power sourceDC
Overview
- Weight
- 5.1 kg
- Colour
- Black
- Number of computers controlled
- 16
- HD type
- WUXGA
- Built-in display
- No
- Power source
- DC
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS17916-AT-G
- Part number
- CS17916-AT-G
- EAN / UPC
- 4719264641602, 6727920055722
- Also known as
- ATEN 16-Port USB - HDMI KVM Switch with USB Peripheral port
Specifications
45 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 16 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 16 |
| USB 2.0 Type-B ports quantity | 16 |
| Console ports | 3.5mm headphone, 3.5mm mic, HDMI, USB A |
| USB hub | Yes |
| USB 2.0 Type-A hub ports quantity | 2 |
| Audio connections | Yes |
| Headphone outputs | 17 |
| Number of microphone inputs | 1 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,5,255 s |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 5 V |
| Power consumption (typical) | 8.66 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 432.4 mm |
| Depth | 257.2 mm |
| Height | 44 mm |
| Weight | 5.1 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 133 mm |
| Package depth | 499 mm |
| Package height | 324 mm |
| Package weight | 5.68 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176200 |
| Master (outer) case net weight | 15.3 kg |
| Master (outer) case width | 427 mm |
| Master (outer) case length | 519 mm |
| Master (outer) case height | 348 mm |
| Master (outer) case gross weight | 18.1 kg |
| Products per master (outer) case | 3 pc(s) |
