ATEN CS1788-AT-E KVM switch Black

ATEN CS1788-AT-E KVM switch Black

Model CS1788-AT-E

41 specifications
  • Weight3.96 kg
  • ColourBlack
  • Number of computers controlled8
  • HD typeWQXGA
  • Built-in displayNo
  • Power sourceDC
See all specifications

Overview

Weight
3.96 kg
Colour
Black
Number of computers controlled
8
HD type
WQXGA
Built-in display
No
Power source
DC
Brand
ATEN
Category
KVM Switch
Model
CS1788-AT-E
Part number
CS1788-AT-E
Also known as
ATEN CS1788-AT-E KVM switch Black

Specifications

41 specifications in 9 groups

Ports & interfaces

Number of computers controlled8
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDVI-I
DVI-I ports quantity8
USB 2.0 Type-B ports quantity8
Console USB ports quantity2
Console ports3.5mm headphone, 3.5mm mic, DVI-I, USB A, VGA (D-Sub)
USB hubYes
USB 2.0 Type-A hub ports quantity2
USB connector typeUSB Type-A, USB Type-B
Audio connectionsYes
Headphone outputs10
Number of microphone inputs10
DC-in jackYes

Performance

HD typeWQXGA
Maximum resolution2560 x 1600 pixels
Video bandwidth60 Hz
Scan interval1,5,255 s

Design

Product colourBlack
Housing materialMetal
LED indicatorsYes
Push buttonYes

Display

Built-in displayNo

Power

Power sourceDC
Input voltage5.3 V
Power consumption (typical)8.26 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Storage relative humidity (H-H)0 - 80%

Weight & dimensions

Width437.2 mm
Depth161.2 mm
Height44 mm
Weight3.96 kg

Packaging data

Package width131 mm
Package depth540 mm
Package height233 mm
Package weight4.48 kg

Packaging content

ManualYes
Quick installation guideYes
