ATEN CS1708I KVM switch Black
Model CS1708IPart no. DCP3005EAN 6727920021376
34 specifications
- ConnectivityWired
- Weight2.81 kg
- ColourBlack
- Number of computers controlled8
- Ethernet LANYes
- Maximum resolution2048 x 1536 pixels
Overview
- Connectivity
- Wired
- Weight
- 2.81 kg
- Colour
- Black
- Number of computers controlled
- 8
- Ethernet LAN
- Yes
- Maximum resolution
- 2048 x 1536 pixels
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS1708I
- Part number
- DCP3005
- EAN / UPC
- 6727920021376, 132018257623, 163121389772, 672792002137 +8 more
- Also known as
- ATEN CS1708I KVM switch Black
Specifications
34 specifications in 11 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 8 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| DVI-I ports quantity | 0 |
| USB 2.0 ports quantity | 1 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Security algorithms | 802.1x RADIUS, SSL/TLS |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 2048 x 1536 pixels |
| Scan interval | 255 s |
| Number of users | 32 user(s) |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 9.5 W |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 160 mm |
| Depth | 433 mm |
| Height | 44 mm |
| Weight | 2.81 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | KVM |
| AC adapter included | Yes |
| Manual | Yes |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Colour depth | 24 bit |
| Compatible operating systems | Windows, Mac OS X, Linux, Sun |
| Ports quantity | 8 |
| RJ-12 ports quantity | 0 |
| I/O ports | 1 x SPHD-18 M 8 x SPHD-17 F 1 x DB-25 M 1 x DC 1 x RJ-45 F 1 x RJ-11 1 x USB A |
