CS1642A KVM switch Rack mounting Black, Silver
Model CS1642APart no. CS1642A-AT-GEAN 4710423779679
40 specifications
- Weight560 g
- ColourBlack, Silver
- Number of computers controlled2
- Maximum resolution2560 x 1600 pixels
- Rack capacity1U
- Built-in displayNo
Overview
- Weight
- 560 g
- Colour
- Black, Silver
- Number of computers controlled
- 2
- Maximum resolution
- 2560 x 1600 pixels
- Rack capacity
- 1U
- Built-in display
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS1642A
- Part numbers
- CS1642A-AT-G, CS1642A
- EAN / UPC
- 4710423779679, 148695866195, 672792004261, 804904089075 +9 more
- Also known as
- ATEN CS1642A KVM switch Rack mounting Black, Silver
Specifications
40 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| DVI-I ports quantity | 6 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, 3.5mm mic, DVI-I, USB A |
| USB 2.0 ports quantity | 4 |
| Audio connections | Yes |
| Headphone outputs | 2 |
| Number of microphone inputs | 1 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 2560 x 1600 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,99 s |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black, Silver |
| Housing material | Metal, Plastic |
| Push button | Yes |
| Hot keys | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 5.3 V |
| Power consumption (typical) | 10.6 W |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | Yes |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 262.3 mm |
| Depth | 76.8 mm |
| Height | 44 mm |
| Weight | 560 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DVI, KVM |
| AC adapter included | Yes |
| Quick installation guide | Yes |
