4-Port USB 5K DisplayPort/HDMI Universal Secure KVM Switch with CAC (PSD PP v4.0 Compliant)
Model CS1184DPH4C-AT-GEAN 4710469349751
38 specifications
- Weight1.21 kg
- ColourBlack
- Number of computers controlled4
- HD type5K Ultra HD
- Rack mountingNo
- Power sourceDC
Overview
- Weight
- 1.21 kg
- Colour
- Black
- Number of computers controlled
- 4
- HD type
- 5K Ultra HD
- Rack mounting
- No
- Power source
- DC
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS1184DPH4C-AT-G
- Part number
- CS1184DPH4C-AT-G
- EAN / UPC
- 4710469349751
- Also known as
- ATEN 4-Port USB 5K DisplayPort/HDMI Universal Secure KVM Switch with CAC (PSD PP v4.0 Compliant)
Specifications
38 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI/DisplayPort |
| HDMI ports quantity | 4 |
| DisplayPorts quantity | 4 |
| USB 2.0 Type-B ports quantity | 8 |
| Console ports | 3.5mm headphone, DisplayPort, HDMI, USB A |
| USB 2.0 Type-A hub ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| RJ-11 ports quantity | 1 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | 5K Ultra HD |
| Maximum resolution | 5120 x 2880 pixels |
| Video bandwidth | 60 Hz |
| Maximum refresh rate | 144 Hz |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.2 A |
| Output voltage | 12 V |
| Power consumption (typical) | 14.88 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 143.6 mm |
| Depth | 245 mm |
| Height | 43 mm |
| Weight | 1.21 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84718000 |
| Country of origin | Taiwan |
