ATEN 4-Port USB DisplayPort Dual Display Secure KVM Switch with CAC (PSD PP v4.0 Compliant)
ATEN

4-Port USB DisplayPort Dual Display Secure KVM Switch with CAC (PSD PP v4.0 Compliant)

Model CS1144DP4CEAN 5715328378629

47 specifications
  • Weight2.37 kg
  • ColourBlack
  • Number of computers controlled4
  • HD type4K Ultra HD
  • Built-in displayNo
  • Power sourceAC
See all specifications

Overview

Weight
2.37 kg
Colour
Black
Number of computers controlled
4
HD type
4K Ultra HD
Built-in display
No
Power source
AC
Brand
ATEN
Category
KVM Switch
Model
CS1144DP4C
Part numbers
CS1144DP4C, CS1144DP4C-AT-G, CS1144DP4C-AT-E
EAN / UPC
5715328378629, 672792013164, 4710469341359
Also known as
ATEN 4-Port USB DisplayPort Dual Display Secure KVM Switch with CAC (PSD PP v4.0 Compliant)

Specifications

47 specifications in 10 groups

Ports & interfaces

Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDisplayPort
DisplayPorts quantity8
USB 2.0 Type-B ports quantity8
Console USB ports quantity2
Console portsDisplayPort, USB A
Console DisplayPorts ports quantity2
USB hubYes
USB 2.0 Type-A hub ports quantity1
Headphone outputs4
RJ-11 ports quantity1

Performance

HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels

Design

Product colourBlack
Housing materialMetal
Wired remote switchYes
LED indicatorsYes
Push buttonYes

Display

Built-in displayNo

Power

Power sourceAC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1.5 A
Power consumption (typical)13.9 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width163.9 mm
Depth335 mm
Height65.5 mm
Weight2.37 kg

Packaging data

Package width131 mm
Package depth540 mm
Package height233 mm
Package volume16480.4047212 cm³
Package weight3.01 kg

Packaging content

Cables includedAC
ManualYes

Logistics data

Master (outer) case net weight7.11 kg
Master (outer) case width420 mm
Master (outer) case length555 mm
Master (outer) case height258 mm
Master (outer) case gross weight9.95 kg
Master (outer) case volume60144.9821784 cm³
Country of originTaiwan
