2-Port USB 5K DisplayPort/HDMI Dual Display Universal Secure KVM Switch with CAC
Model CS1142DPH4CPart no. CS1142DPH4C-AT-U
42 specifications
- Weight1.21 kg
- ColourBlack
- Number of computers controlled2
- HD type5K Ultra HD
- Rack mountingYes
- Built-in displayNo
Overview
- Weight
- 1.21 kg
- Colour
- Black
- Number of computers controlled
- 2
- HD type
- 5K Ultra HD
- Rack mounting
- Yes
- Built-in display
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CS1142DPH4C
- Part number
- CS1142DPH4C-AT-U
- Also known as
- ATEN 2-Port USB 5K DisplayPort/HDMI Dual Display Universal Secure KVM Switch with CAC
Specifications
42 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI/DisplayPort |
| HDMI ports quantity | 4 |
| DisplayPorts quantity | 4 |
| USB 2.0 Type-B ports quantity | 4 |
| Console USB ports quantity | 2 |
| Console ports | HDMI, DisplayPort, USB A |
| Console DisplayPorts ports quantity | 2 |
| Console HDMI ports quantity | 2 |
| USB 2.0 ports quantity | 1 |
| Audio connections | Yes |
| Headphone outputs | 3 |
| RJ-11 ports quantity | 1 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | 5K Ultra HD |
| Maximum resolution | 5120 x 2880 pixels |
| Maximum refresh rate | 144 Hz |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Power, Key lock |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.2 A |
| External power adapter | Yes |
| Power consumption (typical) | 19.56 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 143.6 mm |
| Depth | 245 mm |
| Height | 43 mm |
| Weight | 1.21 kg |
Packaging content
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
| Rubber feet | Yes |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
