CN9950 KVM switch Black
Model CN9950EAN 672792012471
41 specifications
- Weight1.25 kg
- ColourBlack
- Keyboard port typeUSB
- Ethernet LANYes
- HD type4K DCI
- Rack mountingNo
Overview
- Weight
- 1.25 kg
- Colour
- Black
- Keyboard port type
- USB
- Ethernet LAN
- Yes
- HD type
- 4K DCI
- Rack mounting
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CN9950
- Part number
- CN9950
- EAN / UPC
- 672792012471
- Also known as
- ATEN CN9950 KVM switch Black
Specifications
41 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, 3.5mm mic, DisplayPort, USB A |
| USB connector type | Mini-USB |
| PS/2 ports quantity | 1 |
| Serial port type | RJ-45 |
| Serial ports quantity | 2 |
| Audio connections | Yes |
| Headphone outputs | 2 |
| Number of microphone inputs | 2 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
Performance
| Specification | Value |
|---|---|
| HD type | 4K DCI |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 30 Hz |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Input voltage | 5 V |
| Power consumption (typical) | 9.76 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 149.3 mm |
| Depth | 200 mm |
| Height | 28.5 mm |
| Weight | 1.25 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 98 mm |
| Package depth | 325 mm |
| Package height | 210 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DisplayPort, USB |
| AC adapter included | Yes |
| Manual | Yes |
