CN9850-AT-G KVM switch Black
Model CN9850-AT-GEAN 672792016202
44 specifications
- Weight840 g
- ColourBlack
- Keyboard port typeUSB
- HD type4K Ultra HD
- Built-in displayNo
- Power sourceDC
Overview
- Weight
- 840 g
- Colour
- Black
- Keyboard port type
- USB
- HD type
- 4K Ultra HD
- Built-in display
- No
- Power source
- DC
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CN9850-AT-G
- Part number
- CN9850-AT-G
- EAN / UPC
- 672792016202, 4710469349324
- Also known as
- ATEN CN9850-AT-G KVM switch Black
Specifications
44 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 1 |
| USB 2.0 Type-B ports quantity | 1 |
| Console USB ports quantity | 2 |
| Console ports | HDMI, USB A |
| Console HDMI ports quantity | 1 |
| USB connector type | Mini-USB B |
| PS/2 ports quantity | 1 |
| Serial port type | RJ-45 |
| Serial ports quantity | 2 |
| Audio connections | Yes |
| Headphone outputs | 2 |
| Number of microphone inputs | 2 |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Video bandwidth | 30 Hz |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Power |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Output voltage | 5 V |
| Power consumption (typical) | 10.07 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 150.5 mm |
| Depth | 200 mm |
| Height | 28.4 mm |
| Weight | 840 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 98 mm |
| Package depth | 325 mm |
| Package height | 210 mm |
| Package weight | 1.69 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | KVM, USB |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84718000 |
| Master (outer) case width | 342 mm |
| Master (outer) case length | 512 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 9.1 kg |
| Country of origin | Taiwan |
