CN9000 KVM switch Black
Model CN9000EAN 672792012495
31 specifications
- Weight860 g
- ColourBlack
- Number of computers controlled1
- Ethernet LANYes
- HD typeFull HD
- Rack mountingNo
Overview
- Weight
- 860 g
- Colour
- Black
- Number of computers controlled
- 1
- Ethernet LAN
- Yes
- HD type
- Full HD
- Rack mounting
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CN9000
- Part number
- CN9000
- EAN / UPC
- 672792012495
- Also known as
- ATEN CN9000 KVM switch Black
Specifications
31 specifications in 7 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 1 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 2 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, 3.5mm mic, USB A, VGA (D-Sub) |
| USB connector type | USB Type-A |
| Serial port type | RS-232 |
| Serial ports quantity | 1 |
| Audio connections | Yes |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
Performance
| Specification | Value |
|---|---|
| HD type | Full HD |
| Maximum resolution | 1920 x 1200 pixels |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Input voltage | 5 V |
| Power consumption (typical) | 7.46 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 154.1 mm |
| Height | 28.5 mm |
| Weight | 860 g |
