CL3884NW KVM switch Rack mounting Black
Model CL3884NWPart no. CL3884NW-ESEAN 5715063348703
34 specifications
- Display47 cm (18.5")
- Weight11.2 kg
- ColourBlack
- Number of computers controlled4
- Maximum resolution1920 x 1080 pixels
- Rack mountingYes
Overview
- Display
- 47 cm (18.5")
- Weight
- 11.2 kg
- Colour
- Black
- Number of computers controlled
- 4
- Maximum resolution
- 1920 x 1080 pixels
- Rack mounting
- Yes
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CL3884NW
- Part numbers
- CL3884NW-ES, CL3884NW, CL3884NW-FR, CL3884NW-UK, CL3884NW-US
- EAN / UPC
- 5715063348703, 672792010989, 5715063053782, 5715063081440 +1 more
- Also known as
- ATEN CL3884NW KVM switch Rack mounting Black
Specifications
34 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| HDMI ports quantity | 5 |
| USB 2.0 Type-B ports quantity | 4 |
| Console USB ports quantity | 2 |
| Console ports | HDMI, USB A |
| USB connector type | USB Type-A |
| Serial port type | RJ-45 |
| Serial ports quantity | 1 |
| Audio connections | Yes |
Performance
| Specification | Value |
|---|---|
| Maximum resolution | 1920 x 1080 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 5,10,15,30,60,90 s |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Power |
| Push button | Yes |
| Hot keys | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LED |
| Display diagonal | 47 cm (18.5") |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
Sustainability
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 631 mm |
| Depth | 480 mm |
| Height | 42.8 mm |
| Weight | 11.2 kg |
