16-Port USB HDMI Single Rail WideScreen LCD KVM Switch
Model CL3716NX-ATA-XGEAN 4711581521445
42 specifications
- Display47 cm (18.5")
- Weight10.6 kg
- ColourBlack
- Number of computers controlled16
- HD typeWUXGA
- Rack capacity1U
Overview
- Display
- 47 cm (18.5")
- Weight
- 10.6 kg
- Colour
- Black
- Number of computers controlled
- 16
- HD type
- WUXGA
- Rack capacity
- 1U
- Brand
- ATEN
- Category
- KVM Switch
- Model
- CL3716NX-ATA-XG
- Part number
- CL3716NX-ATA-XG
- EAN / UPC
- 4711581521445
- Also known as
- ATEN 16-Port USB HDMI Single Rail WideScreen LCD KVM Switch
Specifications
42 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 16 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 16 |
| USB 2.0 Type-B ports quantity | 16 |
| Console USB ports quantity | 2 |
| Console ports | USB A, HDMI |
| Console HDMI ports quantity | 1 |
| USB connector type | USB Type-A, USB Type-B |
| AC-in ports quantity | 1 |
Performance
| Specification | Value |
|---|---|
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Video bandwidth | 60 Hz |
| Scan interval | 1,255 s |
Design
| Specification | Value |
|---|---|
| Rack capacity | 1U |
| Rack mounting | Yes |
| Product colour | Black |
| Housing material | Metal, Plastic |
| LED indicators | Yes |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 47 cm (18.5") |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 631 mm |
| Depth | 480.6 mm |
| Height | 42.8 mm |
| Weight | 10.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 584 mm |
| Package depth | 449.2 mm |
| Package height | 42.8 mm |
Packaging content
| Specification | Value |
|---|---|
| Quick installation guide | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84718000 |
| Country of origin | China |
