ATEN CL3700NX KVM switch Rack mounting Black

ATEN CL3700NX KVM switch Rack mounting Black

Model CL3700NXPart no. CL3700NX-ATA-XGEAN 4719264647512

51 specifications
  • Display47 cm (18.5")
  • Weight9.03 kg
  • ColourBlack
  • Number of computers controlled1
  • HD typeWXGA
  • Rack capacity1U
See all specifications

Overview

Display
47 cm (18.5")
Weight
9.03 kg
Colour
Black
Number of computers controlled
1
HD type
WXGA
Rack capacity
1U
Brand
ATEN
Category
KVM Switch
Model
CL3700NX
Part number
CL3700NX-ATA-XG
EAN / UPC
4719264647512
Also known as
ATEN CL3700NX KVM switch Rack mounting Black

Specifications

51 specifications in 12 groups

Ports & interfaces

Number of computers controlled1
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
HDMI ports quantity2
Console USB ports quantity2
Console portsUSB A
USB connector typeUSB Type-A
Audio connectionsYes

Performance

HD typeWXGA
Maximum resolution1366 x 768 pixels
Video bandwidth60 Hz
DDC2B supportYes
Firmware upgradeableYes

Design

Rack capacity1U
Rack mountingYes
Product colourBlack
Housing materialMetal, Plastic
LED indicatorsYes
Push buttonYes
Hot keysYes

Display

Built-in displayYes
DisplayLCD
Display diagonal47 cm (18.5")

Power

Power sourceAC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1 A
Power consumption (typical)13.5 W

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width477 mm
Depth480.6 mm
Height42.8 mm
Weight9.03 kg

Packaging data

Package width612 mm
Package depth658 mm
Package height135 mm
Package typeBox

Packaging content

Cables includedAC, KVM
AC adapter includedYes
ManualYes
Quick installation guideYes

Other features

CompatibilityKN2116VA, KN2132VA, KN4116VA, KN4132VA, KN8132V, KN8164V, CS1798, KN2124VA, KN2140VA, KN4124VA, KN4140VA, KN1132V, KN1108VA, KN1116VA, CS17916, 2L-7D02UH, 2K-0001, 2K-0002, 2K-0003, 2K-0004, 2X-040G, 2K-0007, 2X-041G, 2X-042G, CS19208, CS19216, CS1842, CS1844, CS22H, CS18208, CS18216

Logistics data

Master (outer) case net weight9.42 kg
Master (outer) case width612 mm
Master (outer) case length658 mm
Master (outer) case height135 mm
Master (outer) case gross weight11.9 kg
