1-Local Remote Share Access
Model 1-Local Remote Share AccessPart no. RCMDP101U-AX-GEAN 4710469341069
44 specifications
- Weight850 g
- ColourBlack
- Number of computers controlled1
- Ethernet LANYes
- HD type4K Ultra HD
- Built-in displayNo
Overview
- Weight
- 850 g
- Colour
- Black
- Number of computers controlled
- 1
- Ethernet LAN
- Yes
- HD type
- 4K Ultra HD
- Built-in display
- No
- Brand
- ATEN
- Category
- KVM Switch
- Model
- 1-Local Remote Share Access
- Part number
- RCMDP101U-AX-G
- EAN / UPC
- 4710469341069
- Also known as
- ATEN 1-Local/Remote Share Access Single Port 4K DisplayPort KVM over IP Switch
Specifications
44 specifications in 10 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Number of computers controlled | 1 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 2 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone, 3.5mm mic, DisplayPort, USB A |
| Console DisplayPorts ports quantity | 1 |
| Serial port type | RJ-45 |
| Serial ports quantity | 2 |
| Headphone outputs | 2 |
| Number of microphone inputs | 2 |
| DC-in jack | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
Performance
| Specification | Value |
|---|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Push button | Yes |
Display
| Specification | Value |
|---|---|
| Built-in display | No |
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Power consumption (typical) | 9.76 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 149.3 mm |
| Depth | 200 mm |
| Height | 28.5 mm |
| Weight | 850 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 98 mm |
| Package depth | 325 mm |
| Package height | 210 mm |
| Package volume | 6796.04 cm³ |
| Package weight | 1.67 kg |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case net weight | 6.25 kg |
| Master (outer) case width | 342 mm |
| Master (outer) case length | 512 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 8.98 kg |
| Master (outer) case volume | 40776.25 cm³ |
| Country of origin | Taiwan |
