SX8100 1 TB M.2 PCI Express 3.0 NVMe 3D NAND
Model SX8100Part no. ASX8100NP-256GT-CEAN 842243021400
22 specifications
- Storage1 TB
- ConnectivityPCI Express 3.0
- Weight8 g
- Width80 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 1 TB
- Connectivity
- PCI Express 3.0
- Weight
- 8 g
- Width
- 80 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- XPG
- Category
- Internal Solid State Drive
- Model
- SX8100
- Part numbers
- ASX8100NP-256GT-C, ASX8100NP-1TT-C, ASX8100NP-2TT-C, ASX8100NP-4TT-C
- EAN / UPC
- 842243021400, 842243020540, 4710273773704, 842243020557 +2 more
- Also known as
- XPG SX8100 1 TB M.2 PCI Express 3.0 NVMe 3D NAND
Specifications
22 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 1 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| NVMe version | 1.3 |
| Memory type | 3D NAND |
| Component for | PC/Laptop |
| Read speed | 3500 MB/s |
| Write speed | 3000 MB/s |
| Random read (4KB) | 300000 IOPS |
| Random write (4KB) | 240000 IOPS |
| PCI Express interface data lanes | x4 |
| S.M.A.R.T. support | Yes |
| Mean time between failures (MTBF) | 2000000 h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80 mm |
| Depth | 22 mm |
| Height | 3.5 mm |
| Weight | 8 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating shock | 1500 G |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717070 |
