GAMMIX S5
Model GAMMIX S5Part no. AGAMMIXS5-2TT-CEAN 4710273778075
34 specifications
- Storage2 TB
- ConnectivityPCI Express 3.0
- Weight11.2 g
- Width22 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 2 TB
- Connectivity
- PCI Express 3.0
- Weight
- 11.2 g
- Width
- 22 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- XPG
- Category
- Internal Solid State Drive
- Model
- GAMMIX S5
- Part number
- AGAMMIXS5-2TT-C
- EAN / UPC
- 4710273778075
- Also known as
- XPG GAMMIX S5 2 TB M.2 PCI Express 3.0 NVMe 3D TLC
Specifications
34 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 2 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| NVMe version | 1.3 |
| Memory type | 3D TLC |
| Component for | PC |
| Hardware encryption | No |
| Read speed | 2100 MB/s |
| Write speed | 1500 MB/s |
| Random read (4KB) | 250000 IOPS |
| Random write (4KB) | 240000 IOPS |
| Sequential read speed (ATTO) | 2100 MB/s |
| Sequential write speed (ATTO) | 1400 MB/s |
| Sequential read speed (CDM) | 2100 MB/s |
| Sequential write speed (CDM) | 1500 MB/s |
| Sequential read speed (AS SSD) | 1800 MB/s |
| Sequential write speed (AS SSD) | 1300 MB/s |
| Controller type | Realtek |
| PCI Express interface data lanes | x4 |
| ECC | Yes |
| Mean time between failures (MTBF) | 2000000 h |
| TBW rating | 1200 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 22 mm |
| Depth | 80 mm |
| Height | 3.7 mm |
| Weight | 11.2 g |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | 0 °C |
| Operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
