FireCuda 530
2 TB M.2 PCI Express 4.0 NVMe 3D TLC
Model 530Part no. ZP2000GM3A013-10PKEAN 8719706426046
47 specifications
- Storage2 TB
- ConnectivityPCI Express 4.0
- Weight47 g
- Power consumption (average)8 W
- Width24.2 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 2 TB
- Connectivity
- PCI Express 4.0
- Weight
- 47 g
- Power consumption (average)
- 8 W
- Width
- 24.2 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Seagate
- Category
- Internal Solid State Drive
- Model
- 530
- Part numbers
- ZP2000GM3A013-10PK, ZP4000GM3A023-10PK, ZP1000GM30013, ZP2000GM3A023, ZP1000GM3A023, ZP1000GM3A013 +12 more
- EAN / UPC
- 8719706426046, 763649167557, 8719706426039, 763649161753 +12 more
- Also known as
- Seagate FireCuda 530 2 TB M.2 PCI Express 4.0 NVMe 3D TLC
Specifications
47 specifications in 8 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 2 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 4.0 |
| NVMe | Yes |
| NVMe version | 1.4 |
| Memory type | 3D TLC |
| Component for | PC |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Read speed | 7300 MB/s |
| Write speed | 6900 MB/s |
| Random read (4KB) | 1000000 IOPS |
| Random write (4KB) | 1000000 IOPS |
| Controller type | Phison E18 |
| PCI Express interface data lanes | x4 |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Mean time between failures (MTBF) | 1800000 h |
| Windows operating systems supported | Windows 10 |
| Linux operating systems supported | Yes |
| TBW rating | 2550 |
Power
| Specification | Value |
|---|---|
| Power consumption (average) | 8 W |
| Power consumption (idle) | 0.024 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 24.2 mm |
| Depth | 80.2 mm |
| Height | 10.4 mm |
| Weight | 47 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 109 mm |
| Package depth | 24 mm |
| Package height | 134.2 mm |
| Package weight | 62 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | 40 - 85 °C |
| Non-operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Technical details
| Specification | Value |
|---|---|
| Doesn't contain | Halogen |
Logistics data
| Specification | Value |
|---|---|
| Pallet gross height | 70.6 cm |
| Pallet gross length | 121.9 cm |
| Pallet gross weight | 47.5 kg |
| Pallet gross width | 50.8 cm |
| Master (outer) cases per pallet | 48 pc(s) |
| Layers per pallet | 4 pc(s) |
| Products per pallet | 480 pc(s) |
| Master (outer) case width | 278 mm |
| Harmonized System (HS) code | 84717070 |
| Master (outer) case length | 169 mm |
| Master (outer) case gross weight | 920 g |
| Products per master (outer) case | 10 pc(s) |
