PM863a 480 GB 2.5" Serial ATA III TLC
Model PM863aPart no. MZ7LM1T9HMJP-00005EAN 8592978095307
30 specifications
- Storage480 GB
- ConnectivitySerial ATA III
- Weight54.34 g
- ColourBlack
- Operating voltage5 V
- Width100 mm
Overview
- Storage
- 480 GB
- Connectivity
- Serial ATA III
- Weight
- 54.34 g
- Colour
- Black
- Operating voltage
- 5 V
- Width
- 100 mm
- Brand
- Samsung
- Category
- Internal Solid State Drive
- Model
- PM863a
- Part numbers
- MZ7LM1T9HMJP-00005, MZ-7LM1T9NE, MZ-7LM3T8NE, MZ-7LM480NE, MZ-7LM960NE, MZ7LM480HMHQ-0005 +9 more
- EAN / UPC
- 8592978095307, 000065468463, 571178385034, 672042109715 +33 more
- Also known as
- Samsung PM863a 480 GB 2.5" Serial ATA III TLC
Specifications
30 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 480 GB |
| SSD form factor | 2.5" |
| Interface | Serial ATA III |
| Memory type | TLC |
| Hardware encryption | Yes |
| Security algorithms | 256-bit AES |
| Data transfer rate | 6 Gbit/s |
| Read speed | 520 MB/s |
| Write speed | 480 MB/s |
| Random read (4KB) | 97000 IOPS |
| Random write (4KB) | 16000 IOPS |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Operating voltage | 5 V |
| Power consumption (read) | 3 W |
| Power consumption (write) | 3 W |
| Power consumption (idle) | 1.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 6.8 mm |
| Height | 68.8 mm |
| Weight | 54.34 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Product colour | Black |
| NAND controller | V-NAND |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717070 |
