990 EVO Plus
Model 990 EVO PlusPart no. MZ-V9S2T0B/AMEAN 887276843667
33 specifications
- Storage2 TB
- ConnectivityPCI Express 4.0
- Power consumption (read)4.3 W
- Width80.2 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 2 TB
- Connectivity
- PCI Express 4.0
- Power consumption (read)
- 4.3 W
- Width
- 80.2 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Samsung
- Category
- Internal Solid State Drive
- Model
- 990 EVO Plus
- Part numbers
- MZ-V9S2T0B/AM, MZ-V9S1T0B/AM, MZ-V9S4T0B/AM
- EAN / UPC
- 887276843667, 887276843674, 887276843711
- Also known as
- Samsung 990 EVO Plus 2 TB M.2 PCI Express 4.0 NVMe V-NAND TLC
Specifications
33 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 2 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 4.0 |
| NVMe | Yes |
| NVMe version | 2.0 |
| Memory type | V-NAND TLC |
| Component for | PC/Laptop |
| Hardware encryption | Yes |
| Security algorithms | 256-bit AES |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Read speed | 7250 MB/s |
| Write speed | 6300 MB/s |
| Random read (4KB) | 1000000 IOPS |
| Random write (4KB) | 1350000 IOPS |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Mean time between failures (MTBF) | 1500000 h |
| TBW rating | 1200 |
Power
| Specification | Value |
|---|---|
| Power consumption (read) | 4.3 W |
| Power consumption (write) | 4.2 W |
| Power consumption (idle) | 0.06 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80.2 mm |
| Depth | 22.1 mm |
| Height | 2.38 mm |
Packaging data
| Specification | Value |
|---|---|
| Package type | Hanging box |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating shock | 1500 G |
| Vibration resistance | 20 G |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | KCC, Federal Communications Commission (FCC), CE |
| Warranty period | 5 year(s) |
