970 PRO
Model 970 PROPart no. MZ-V7P1T0B/AMEAN 887276263304
48 specifications
- Storage512 GB
- ConnectivityPCI Express 3.0
- Weight8 g
- ColourBlack
- Operating voltage3.3 V
- Width80.2 mm
Overview
- Storage
- 512 GB
- Connectivity
- PCI Express 3.0
- Weight
- 8 g
- Colour
- Black
- Operating voltage
- 3.3 V
- Width
- 80.2 mm
- Brand
- Samsung
- Category
- Internal Solid State Drive
- Model
- 970 PRO
- Part numbers
- MZ-V7P1T0B/AM, MZ-V7P512B/AM, MZ-V7P1T0BW, MZ-V7P512BW, MZ-V7P1T0E, MZ-V7P512E
- EAN / UPC
- 887276263304, 887276261928, 5706998249159, 8801643205379 +5 more
- Also known as
- Samsung 970 PRO 512 GB M.2 PCI Express 3.0 NVMe V-NAND MLC
Specifications
48 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 512 GB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| NVMe version | 1.3 |
| Memory type | V-NAND MLC |
| NAND flash type | MLC (Multi Level Cell) |
| Component for | PC |
| Security algorithms | 256-bit AES |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Read speed | 3500 MB/s |
| Write speed | 2300 MB/s |
| Random read (4KB) | 370000 IOPS |
| Random write (4KB) | 500000 IOPS |
| Controller type | Samsung Phoenix |
| PCI Express interface data lanes | x4 |
| DevSlp (device sleep) support | Yes |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Mean time between failures (MTBF) | 1500000 h |
| Opal SSC 2.0 | Yes |
| TCG Opal 2.0 | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 3.3 V |
| Power consumption (read) | 5.2 W |
| Power consumption (write) | 5.2 W |
| Power consumption (max) | 8.5 W |
| Power consumption (average) | 5.2 W |
| Power consumption (idle) | 0.03 W |
| Power consumption DevSlp (device sleep) | 5 mW |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 80.2 mm |
| Depth | 2.38 mm |
| Height | 22.1 mm |
| Weight | 8 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 143.4 mm |
| Package depth | 98.1 mm |
| Package height | 21.7 mm |
| Package weight | 78 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -45 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating vibration | 20 G |
| Operating shock | 1500 G |
| Non-operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Product colour | Black |
| Compliance certificates | RoHS |
| Launch date | 4/16/2018 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717070 |
