830 Series
Model 830 SeriesPart no. MZ-7PC064D/AMEAN 5053106337018
29 specifications
- Storage64 GB
- ConnectivitySerial ATA
- Weight61 g
- ColourBlack
- Operating voltage5 V
- Width100 mm
Overview
- Storage
- 64 GB
- Connectivity
- Serial ATA
- Weight
- 61 g
- Colour
- Black
- Operating voltage
- 5 V
- Width
- 100 mm
- Brand
- Samsung
- Category
- Internal Solid State Drive
- Model
- 830 Series
- Part numbers
- MZ-7PC064D/AM, MZ-7PC512D/AM, MZ-7PC512N/AM, MZ-7PC064Z, MZ-7PC256Z, MZ-7PC064B/WW +14 more
- EAN / UPC
- 5053106337018, 3610170528630, 5053106462475, 8806071719597 +40 more
- Also known as
- Samsung 830 Series 64 GB 2.5" Serial ATA
Specifications
29 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 64 GB |
| SSD form factor | 2.5" |
| Interface | Serial ATA |
| Data transfer rate | 6 Gbit/s |
| Read speed | 520 MB/s |
| Write speed | 160 MB/s |
| Random read (4KB) | 75000 IOPS |
| Random write (4KB) | 16000 IOPS |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Mean time between failures (MTBF) | 1500000 h |
Power
| Specification | Value |
|---|---|
| Operating voltage | 5 V |
| Power consumption (read) | 0.127 W |
| Power consumption (write) | 0.127 W |
| Power consumption (standby) | 0.078 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 69.8 mm |
| Height | 7 mm |
| Weight | 61 g |
Packaging data
| Specification | Value |
|---|---|
| Cables included | SATA |
| Quick start guide | Yes |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating vibration | 1500 G |
| Operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Product colour | Black |
