Origin Storage SSD 512GB 2.5in SATA 3D TLC in Hot Swap Caddy

Origin Storage SSD 512GB 2.5in SATA 3D TLC in Hot Swap Caddy

Model DELL-5123DTLC-F25EAN 5056006161592

41 specifications

Storage512 GB
ConnectivitySerial ATA
Operating voltage5 V
Operating temperature (T-T)0 - 70 °C

See all specifications

Overview

Storage: 512 GB
Connectivity: Serial ATA
Operating voltage: 5 V
Operating temperature (T-T): 0 - 70 °C

Brand: Origin Storage
Category: Internal Solid State Drive
Model: DELL-5123DTLC-F25
Part number: DELL-5123DTLC-F25
EAN / UPC: 5056006161592
Also known as: Origin Storage SSD 512GB 2.5in SATA 3D TLC in Hot Swap Caddy

Specifications

41 specifications in 6 groups

Features

Specification	Value
SSD capacity	512 GB
SSD form factor	2.5"
Interface	Serial ATA
NVMe	No
Memory type	3D TLC
Component for	PC/Laptop
Hardware encryption	No
Data transfer rate	6 Gbit/s
Read speed	550 MB/s
Write speed	500 MB/s
Random read (4KB)	53760 IOPS
Random write (4KB)	56320 IOPS
Access time	0.1 ms
Seek time	0 ms
S.M.A.R.T. support	Yes
TRIM support	Yes
Hot-swap	No
Mean time between failures (MTBF)	1000000 h
Windows operating systems supported	Yes
Linux operating systems supported	Yes
TBW rating	100

Power

Specification	Value
Operating voltage	5 V
Power consumption (read)	3.1 W
Power consumption (write)	4.55 W
Power consumption (max)	4.55 W
Power consumption (average)	3.825 W
Power consumption (idle)	0.54 W

Packaging data

Specification	Value
Storage drive adapter included	No
Screws included	No
Package type	Blister

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-45 - 105 °C
Operating relative humidity (H-H)	5 - 98%
Storage relative humidity (H-H)	5 - 98%
Operating vibration	16 G
Operating shock	1500 G
Maximum operating altitude	36576 m

Other features

Specification	Value
Compliance certificates	RoHS
Compatible products	Universal
Warranty period	5 year(s)

Logistics data

Specification	Value
Harmonized System (HS) code	84717070
