400GB EMLC PE M520/M620/M820
2.5in SATA SSD HotSwap Kit
Model DELL-400EMLCSA-S15EAN 5055146596516
32 specifications
- Storage400 GB
- ConnectivitySerial ATA III
- Weight88 g
- Power consumption (average)5.4 W
- Intel High Endurance Technology (HET)Yes
- Width69.8 mm
Overview
- Storage
- 400 GB
- Connectivity
- Serial ATA III
- Weight
- 88 g
- Power consumption (average)
- 5.4 W
- Intel High Endurance Technology (HET)
- Yes
- Width
- 69.8 mm
- Brand
- Origin Storage
- Category
- Internal Solid State Drive
- Model
- DELL-400EMLCSA-S15
- Part number
- DELL-400EMLCSA-S15
- EAN / UPC
- 5055146596516
- Also known as
- Origin Storage 400GB EMLC PE M520/M620/M820 2.5in SATA SSD HotSwap Kit
Specifications
32 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 400 GB |
| SSD form factor | 2.5" |
| Interface | Serial ATA III |
| NVMe | No |
| Memory type | eMLC |
| NAND flash type | MLC (Multi Level Cell) |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| Security algorithms | 256-bit AES |
| Data transfer rate | 6 Gbit/s |
| Read speed | 550 MB/s |
| Write speed | 470 MB/s |
| Random read (100% span) | 85000 IOPS |
| Random write (100% span) | 43000 IOPS |
| Read latency | 55 µs |
| Write latency | 66 µs |
| Lithography | 20 nm |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Enhanced Power Loss Data Protection technology | Yes |
| Native Command Queuing (NCQ) | Yes |
| SSD temperature monitoring | Yes |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (average) | 5.4 W |
| Power consumption (idle) | 0.6 W |
Brand-specific features
| Specification | Value |
|---|---|
| Intel High Endurance Technology (HET) | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 69.8 mm |
| Depth | 100.5 mm |
| Height | 7 mm |
| Weight | 88 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating shock | 1000 G |
| Non-operating shock | 1000 G |
