128GB SATA Latitude E6330
2.5in MLC SSD Main/1st SATA Kit
Model DELL-128MLCPRO-NB66EAN 5055146593805
34 specifications
- Storage128 GB
- ConnectivitySerial ATA
- Weight63.5 g
- Operating voltage5 V
- Width69.8 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 128 GB
- Connectivity
- Serial ATA
- Weight
- 63.5 g
- Operating voltage
- 5 V
- Width
- 69.8 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Origin Storage
- Category
- Internal Solid State Drive
- Model
- DELL-128MLCPRO-NB66
- Part number
- DELL-128MLCPRO-NB66
- EAN / UPC
- 5055146593805
- Also known as
- Origin Storage 128GB SATA Latitude E6330 2.5in MLC SSD Main/1st SATA Kit
Specifications
34 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 128 GB |
| SSD form factor | 2.5" |
| Interface | Serial ATA |
| NVMe | No |
| Memory type | MLC |
| NAND flash type | MLC (Multi Level Cell) |
| Component for | Laptop |
| Security algorithms | 256-bit AES |
| Data transfer rate | 6 Gbit/s |
| Read speed | 550 MB/s |
| Write speed | 470 MB/s |
| Random read (4KB) | 100000 IOPS |
| Random write (4KB) | 90000 IOPS |
| DevSlp (device sleep) support | Yes |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| IEEE 1667 | Yes |
| Mean time between failures (MTBF) | 2000000 h |
| Active garbage collection | Yes |
| Windows operating systems supported | Yes |
| Opal SSC 2.0 | Yes |
| Linux operating systems supported | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 5 V |
| Power consumption (max) | 3.1 W |
| Power consumption (average) | 2.8 W |
| Power consumption (idle) | 0.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 69.8 mm |
| Depth | 100.5 mm |
| Height | 7 mm |
| Weight | 63.5 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Operating shock | 1500 G |
Other features
| Specification | Value |
|---|---|
| Internal | Yes |
| Compatible products | Dell Latitude E6330 |
