SPATIUM M480 PRO PCIe 4.0 NVMe M.2 PLAY
Model SPATIUM M480 PRO PCIe 4.0 NVMe M.2 PLAYPart no. S78-440Q620-P83EAN 4711377105699
33 specifications
- Storage2 TB
- ConnectivityPCI Express 4.0
- Power consumption (max)10.5 W
- Width24 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 2 TB
- Connectivity
- PCI Express 4.0
- Power consumption (max)
- 10.5 W
- Width
- 24 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- MSI
- Category
- Internal Solid State Drive
- Model
- SPATIUM M480 PRO PCIe 4.0 NVMe M.2 PLAY
- Part number
- S78-440Q620-P83
- EAN / UPC
- 4711377105699
- Also known as
- MSI SPATIUM M480 PRO PCIe 4.0 NVMe M.2 PLAY 2 TB PCI Express 4.0 3D NAND
Specifications
33 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 2 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 4.0 |
| NVMe | Yes |
| NVMe version | 1.4 |
| Memory type | 3D NAND |
| Component for | PC/Game console |
| Hardware encryption | Yes |
| Security algorithms | 256-bit AES |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Random read (4KB) | 1000000 IOPS |
| Random write (4KB) | 1000000 IOPS |
| Sequential read speed (ATTO) | 7400 MB/s |
| Sequential write speed (ATTO) | 7000 MB/s |
| Controller type | Phison E18 |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| ECC | Yes |
| End-to-End Data Protection | Yes |
| External DDR cache | Yes |
| External DDR cache quantity | 2000 MB |
| SSD temperature monitoring | Yes |
| Mean time between failures (MTBF) | 1600000 h |
| Windows operating systems supported | Windows 11 |
| TBW rating | 1400 |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 10.5 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 24 mm |
| Depth | 80.4 mm |
| Height | 10.7 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | 0 °C |
