M370 1 TB M.2 PCI Express 3.0 NVMe 3D NAND
Model M370Part no. SM370N1TBEAN 824142247266
29 specifications
- Storage1 TB
- ConnectivityPCI Express 3.0
- Power consumption (max)3.6 W
- Width22 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 1 TB
- Connectivity
- PCI Express 3.0
- Power consumption (max)
- 3.6 W
- Width
- 22 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- MSI
- Category
- Internal Solid State Drive
- Model
- M370
- Part numbers
- SM370N1TB, SM370N2TB
- EAN / UPC
- 824142247266, 824142247273
- Also known as
- MSI M370 1 TB M.2 PCI Express 3.0 NVMe 3D NAND
Specifications
29 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 1 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| NVMe version | 1.3 |
| Memory type | 3D NAND |
| Component for | PC/Laptop |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Target workload | Mixed Use (MU) |
| Random read (4KB) | 215000 IOPS |
| Random write (4KB) | 330000 IOPS |
| Sequential read speed (CDM) | 2400 MB/s |
| Sequential write speed (CDM) | 1750 MB/s |
| Controller type | Phison E13T |
| PCI Express interface data lanes | x4 |
| PCI Express CEM revision | 3.0 |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| ECC | Yes |
| End-to-End Data Protection | Yes |
| Mean time between failures (MTBF) | 1500000 h |
| TBW rating | 800 |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 3.6 W |
| Power consumption (idle) | 0.3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 22 mm |
| Depth | 80 mm |
| Height | 2.15 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
