960GB SSD MS SATA SIMPLE SWAP 3.5 S4610
Model 960GB SSD MS SATA SIMPLE SWAP 3.5 S4610Part no. 4XB7A13962
35 specifications
- Storage960 GB
- ConnectivitySerial ATA III
- Weight484 g
- Power consumption (write)3 W
- Width257 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 960 GB
- Connectivity
- Serial ATA III
- Weight
- 484 g
- Power consumption (write)
- 3 W
- Width
- 257 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Lenovo
- Category
- Internal Solid State Drive
- Model
- 960GB SSD MS SATA SIMPLE SWAP 3.5 S4610
- Part number
- 4XB7A13962
- Also known as
- Lenovo 960GB SSD MS SATA SIMPLE SWAP 3.5 S4610 3.5" Serial ATA III 3D TLC NAND
Specifications
35 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 960 GB |
| SSD form factor | 3.5" |
| Interface | Serial ATA III |
| NVMe | No |
| Memory type | 3D TLC NAND |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| Security algorithms | 256-bit AES |
| Data transfer rate | 6 Gbit/s |
| Random read (4KB) | 96000 IOPS |
| Random write (4KB) | 51000 IOPS |
| Random latency - read (up to) | 103 µs |
| Random latency - write (up to) | 54 µs |
| Read latency | 36 µs |
| Write latency | 37 µs |
| S.M.A.R.T. support | Yes |
| Hot-swap | Yes |
| End-to-End Data Protection | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Drive writes per day (DWPD) | 3.4 |
| Mean time between failures (MTBF) | 2000000 h |
| Certification | FCC Title 47, Part 15B, Class B CA/CSA-CEI/IEC CISPR 22:02 EN 55024: 1998 EN 55022: 2006 EN-60950-1 2nd Edition UL/CSA EN-60950-1 2nd Edition Low Voltage Directive 2006/95/EC C-Tick: AS/NZS3584 BSMI: CNS 13438 KCC Article 11.1 RoHS DIRECTIVE 2011/65/EU WEEE Directive 2002/96/EC |
Power
| Specification | Value |
|---|---|
| Power consumption (write) | 3 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 257 mm |
| Depth | 193 mm |
| Height | 95 mm |
| Weight | 484 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -55 - 95 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating vibration | 2.17 G |
| Non-operating vibration | 3.13 G |
| Operating shock | 1000 G |
| Maximum operating altitude | 3050 m |
Other features
| Specification | Value |
|---|---|
| Endurance rating | 6 PB |
