4XB7A70006 internal solid state drive
400 GB 2.5" SAS 3D eTLC
Model 4XB7A70006EAN 889488566839
30 specifications
- Storage400 GB
- ConnectivitySAS
- Weight136 g
- Power consumption (read)8.9 W
- Width70 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 400 GB
- Connectivity
- SAS
- Weight
- 136 g
- Power consumption (read)
- 8.9 W
- Width
- 70 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Lenovo
- Category
- Internal Solid State Drive
- Model
- 4XB7A70006
- Part number
- 4XB7A70006
- EAN / UPC
- 889488566839
- Also known as
- Lenovo 4XB7A70006 internal solid state drive 400 GB 2.5" SAS 3D eTLC
Specifications
30 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 400 GB |
| SSD form factor | 2.5" |
| Interface | SAS |
| NVMe | No |
| Memory type | 3D eTLC |
| Component for | Server/workstation |
| Security algorithms | 256-bit AES |
| Data transfer rate | 12 Gbit/s |
| Random read (4KB) | 170000 IOPS |
| Random write (4KB) | 200000 IOPS |
| Read latency | 115 µs |
| Write latency | 25 µs |
| S.M.A.R.T. support | Yes |
| Hot-swap | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2500000 h |
| Certification | UL TUV FCC IC CB CE Mark C-Tick Mark BSMI (Taiwan) KCC (Korea EMI) VCCI |
Power
| Specification | Value |
|---|---|
| Power consumption (read) | 8.9 W |
| Power consumption (write) | 7.9 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 70 mm |
| Depth | 100 mm |
| Height | 15 mm |
| Weight | 136 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Non-operating vibration | 11.08 G |
| Non-operating shock | 1000 G |
| Maximum operating altitude | 4572 m |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
