4XB7A38240 internal solid state drive
6.4 TB Half-Height/Half-Length (HH/HL) PCI Express 3.0 NVMe TLC 3D NAND
Model 4XB7A38240EAN 889488522033
25 specifications
- Storage6.4 TB
- ConnectivityPCI Express 3.0
- Weight220 g
- Power consumption (max)16 W
- Width168 mm
- Operating temperature (T-T)0 - 50 °C
Overview
- Storage
- 6.4 TB
- Connectivity
- PCI Express 3.0
- Weight
- 220 g
- Power consumption (max)
- 16 W
- Width
- 168 mm
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- Lenovo
- Category
- Internal Solid State Drive
- Model
- 4XB7A38240
- Part number
- 4XB7A38240
- EAN / UPC
- 889488522033
- Also known as
- Lenovo 4XB7A38240 internal solid state drive 6.4 TB Half-Height/Half-Length (HH/HL) PCI Express 3.0 NVMe TLC 3D NAND
Specifications
25 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 6.4 TB |
| SSD form factor | Half-Height/Half-Length (HH/HL) |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| Memory type | TLC 3D NAND |
| Component for | Server/workstation |
| Random read (4KB) | 718000 IOPS |
| Random write (4KB) | 117000 IOPS |
| Random latency - read (up to) | 106 µs |
| Random latency - write (up to) | 10 µs |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2500000 h |
| Certification | Underwriters Laboratories: UL60950-1 Canada: CAN/CSA-C22.2 No.60950-1 TUV: EN 60950-1 BSMI (Taiwan): CNS 13438 (CISPR Pub. 22 Class B): D33003 MSIP: KN22, KN24 (CISPR Pub. 22 Class B) Australia/New Zealand: AS/NZS CISPR32:2015 Class B Canada: ICES-003 Issue 6 Class B EMC: EN55022 (2010) Class B EMC: |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 16 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 168 mm |
| Depth | 19 mm |
| Height | 69 mm |
| Weight | 220 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating vibration | 2.17 G |
| Operating shock | 400 G |
| Maximum non-operating altitude | 12192 m |
| Maximum operating altitude | 5486 m |
