4XB7A17100 internal solid state drive
3.84 TB 3.5" Serial ATA III 3D TLC NAND
Model 4XB7A17100EAN 889488511198
31 specifications
- Storage3.84 TB
- ConnectivitySerial ATA III
- Weight484 g
- Power consumption (read)2.5 W
- Width257 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 3.84 TB
- Connectivity
- Serial ATA III
- Weight
- 484 g
- Power consumption (read)
- 2.5 W
- Width
- 257 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Lenovo
- Category
- Internal Solid State Drive
- Model
- 4XB7A17100
- Part number
- 4XB7A17100
- EAN / UPC
- 889488511198
- Also known as
- Lenovo 4XB7A17100 internal solid state drive 3.84 TB 3.5" Serial ATA III 3D TLC NAND
Specifications
31 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 3.84 TB |
| SSD form factor | 3.5" |
| Interface | Serial ATA III |
| Memory type | 3D TLC NAND |
| Component for | Server/workstation |
| Hardware encryption | Yes |
| Security algorithms | 256-bit AES |
| Data transfer rate | 6 Gbit/s |
| Read speed | 540 MB/s |
| Write speed | 520 MB/s |
| Random read (4KB) | 95000 IOPS |
| Random write (4KB) | 34000 IOPS |
| Read latency | 250 µs |
| Write latency | 200 µs |
| S.M.A.R.T. support | Yes |
| Hot-swap | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Drive writes per day (DWPD) | 3.5 |
| Mean time between failures (MTBF) | 3000000 h |
| Certification | Micron Green Standard Built with sulfur resistant resistors CE (Europe): EN 55032 Class B, RoHS FCC: CFR Title 47, Part 15 Class B UL: UL-60950-1, 2nd Edition BSMI (Taiwan): approval to CNS 13438 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KCC RRL (Korea): approval to KN 32 Class B, KN 35 C |
Power
| Specification | Value |
|---|---|
| Power consumption (read) | 2.5 W |
| Power consumption (write) | 3.8 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 257 mm |
| Depth | 193 mm |
| Height | 95 mm |
| Weight | 484 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating shock | 1.5 G |
| Non-operating shock | 3.13 G |
