4XB7A13658 internal solid state drive
1.6 TB 3.5" SAS 3D NAND
Model 4XB7A13658EAN 889488475483
29 specifications
- Storage1.6 TB
- ConnectivitySAS
- Power consumption (read)9 W
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 1.6 TB
- Connectivity
- SAS
- Power consumption (read)
- 9 W
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Lenovo
- Category
- Internal Solid State Drive
- Model
- 4XB7A13658
- Part number
- 4XB7A13658
- EAN / UPC
- 889488475483
- Also known as
- Lenovo 4XB7A13658 internal solid state drive 1.6 TB 3.5" SAS 3D NAND
Specifications
29 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 1.6 TB |
| SSD form factor | 3.5" |
| Interface | SAS |
| Memory type | 3D NAND |
| Component for | Server/workstation |
| Data transfer rate | 12 Gbit/s |
| Read speed | 1000 MB/s |
| Write speed | 1200 MB/s |
| Random read (4KB) | 230000 IOPS |
| Random write (4KB) | 90000 IOPS |
| Read latency | 106 µs |
| Write latency | 60 µs |
| S.M.A.R.T. support | Yes |
| Hot-swap | Yes |
| End-to-End Data Protection | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| Mean time between failures (MTBF) | 2000000 h |
| TBW rating | 8760 |
| Certification | UL,TUV,FCC,IC,CB,CE, C-Tick, BSMI, KCC, VCCI |
Power
| Specification | Value |
|---|---|
| Power consumption (read) | 9 W |
| Power consumption (write) | 9 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating vibration | 20 G |
| Operating shock | 1500 G |
| Maximum operating altitude | 4572 m |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
