250G NV2 M.2 2280 PCIe 4.0 NVMe SSD
Model NV2Part no. SNV2S/4000GEAN 740617329940
32 specifications
- Storage250 GB
- ConnectivityPCI Express 4.0
- Weight7 g
- Width22 mm
- Operating temperature (T-T)-40 - 85 °C
Overview
- Storage
- 250 GB
- Connectivity
- PCI Express 4.0
- Weight
- 7 g
- Width
- 22 mm
- Operating temperature (T-T)
- -40 - 85 °C
- Brand
- Kingston Technology
- Category
- Internal Solid State Drive
- Model
- NV2
- Part numbers
- SNV2S/4000G, SNV2S/250G, SNV2S/500G, SNV2S/1000G, SNV2S/2000G, SNV2S/250GBK +3 more
- EAN / UPC
- 740617329940, 740617329889, 740617329858, 740617329919 +5 more
- Also known as
- Kingston Technology 250G NV2 M.2 2280 PCIe 4.0 NVMe SSD
Specifications
32 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 250 GB |
| SSD form factor | M.2 |
| Interface | PCI Express 4.0 |
| NVMe | Yes |
| Memory type | 3D NAND |
| Component for | PC/Laptop |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Read speed | 3000 MB/s |
| Write speed | 1300 MB/s |
| PCI Express interface data lanes | x4 |
| Mean time between failures (MTBF) | 2000000 h |
| TBW rating | 1280 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 22 mm |
| Depth | 80 mm |
| Height | 3.5 mm |
| Weight | 7 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 129.5 mm |
| Package depth | 8.4 mm |
| Package height | 184.2 mm |
| Package weight | 10 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 85 °C |
| Storage temperature (T-T) | 0 - 70 °C |
| Operating vibration | 2.17 G |
| Non-operating vibration | 20 G |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | CE, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China, Taiwan |
| Master (outer) case width | 135.9 mm |
| Master (outer) case length | 203.2 mm |
| Master (outer) case height | 69.9 mm |
| Master (outer) case gross weight | 393.6 g |
| Products per master (outer) case | 10 pc(s) |
