FURY Renegade G5
Model FURY Renegade G5Part no. SFYR2S/4T0EAN 740617349504
35 specifications
- Storage8 TB
- ConnectivityPCI Express 5.0
- Weight8.9 g
- Power consumption (max)9.5 W
- Width22 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 8 TB
- Connectivity
- PCI Express 5.0
- Weight
- 8.9 g
- Power consumption (max)
- 9.5 W
- Width
- 22 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- Kingston Technology
- Category
- Internal Solid State Drive
- Model
- FURY Renegade G5
- Part numbers
- SFYR2S/4T0, SFYR2D/8T1, SFYR2S/1T0, SFYR2S/2T0
- EAN / UPC
- 740617349504, 740617351613, 740617349481, 7406173494814 +2 more
- Also known as
- Kingston Technology 8T FURY RENEGADE G5 M.2 2280 NVMe SSD
Specifications
35 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 8 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 5.0 |
| NVMe | Yes |
| Memory type | 3D TLC |
| Component for | PC/Laptop |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Read speed | 14800 MB/s |
| Write speed | 14000 MB/s |
| Random read (4KB) | 2200000 IOPS |
| Random write (4KB) | 2200000 IOPS |
| Controller type | SMI SM2508 |
| PCI Express interface data lanes | x4 |
| External DDR cache | Yes |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 9.5 W |
| Power consumption (average) | 0.27 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 22 mm |
| Depth | 80 mm |
| Height | 3.8 mm |
| Weight | 8.9 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 72.4 mm |
| Package depth | 17.5 mm |
| Package height | 128.5 mm |
| Package weight | 33.6 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating vibration | 2.17 G |
| Non-operating vibration | 20 G |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China, Taiwan |
| Master (outer) case width | 139.7 mm |
| Master (outer) case length | 222.2 mm |
| Master (outer) case height | 184.2 mm |
| Master (outer) case gross weight | 843.91 g |
| Products per master (outer) case | 20 pc(s) |
