M30 1 TB M.2 PCI Express 3.0 NVMe TLC 3D NAND
Model M30Part no. GP-GM301TB-GEAN 889523028261
24 specifications
- Storage1 TB
- ConnectivityPCI Express 3.0
- Current0.9 A
- Width22 mm
- Operating temperature (T-T)0 - 70 °C
Overview
- Storage
- 1 TB
- Connectivity
- PCI Express 3.0
- Current
- 0.9 A
- Width
- 22 mm
- Operating temperature (T-T)
- 0 - 70 °C
- Brand
- GIGABYTE
- Category
- Internal Solid State Drive
- Model
- M30
- Part numbers
- GP-GM301TB-G, GP-GM30512G-G
- EAN / UPC
- 889523028261, 4719331822668, 4719331822828
- Also known as
- GIGABYTE M30 1 TB M.2 PCI Express 3.0 NVMe TLC 3D NAND
Specifications
24 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| SSD capacity | 1 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| NVMe | Yes |
| NVMe version | 1.3 |
| Memory type | TLC 3D NAND |
| Component for | PC/Laptop |
| Read speed | 3500 MB/s |
| Write speed | 3000 MB/s |
| Random read (4KB) | 308 IOPS |
| Random write (4KB) | 332 IOPS |
| PCI Express interface data lanes | x4 |
| Mean time between failures (MTBF) | 2000000 h |
Power
| Specification | Value |
|---|---|
| Current | 0.9 A |
| Power consumption (read) | 5.9 W |
| Power consumption (write) | 5 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 22 mm |
| Depth | 80 mm |
| Height | 2.3 mm |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | 0 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717070 |
