Samsung 500GB Serial ATA II HDD, 20-pk
Model 500GB Serial ATA II HDD, 20-pkPart no. HD501LJ?20PK
28 specifications
- Storage500 GB
- ConnectivitySerial ATA II
- Power consumption (typical)8 W
- Operating temperature (T-T)0 - 60 °C
Overview
- Storage
- 500 GB
- Connectivity
- Serial ATA II
- Power consumption (typical)
- 8 W
- Operating temperature (T-T)
- 0 - 60 °C
- Brand
- Samsung
- Category
- Internal Hard Drive
- Model
- 500GB Serial ATA II HDD, 20-pk
- Part number
- HD501LJ?20PK
- Also known as
- Samsung Spinpoint T 500GB Serial ATA II HDD, 20-pk internal hard drive 7200 RPM 16 MB 3.5"
Specifications
28 specifications in 4 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 500 GB |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| Interface | Serial ATA II |
| Storage drive buffer size | 16 MB |
| Full stroke seek time | 18 ms |
| Track to track seek time | 0.8 ms |
| Average seek time | 8.9 ms |
| Average latency | 4.17 ms |
| Bytes per sector | 512 |
| Start/stop cycles | 50000 |
| Mean time between failures (MTBF) | 600000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 8 W |
| Power consumption (standby) | 1.2 W |
| Operating voltage | 5 / 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 12000 m |
| Operating shock | 63 G |
| Non-operating shock | 300 G |
Other features
| Specification | Value |
|---|---|
| Power requirements | +5V; +12V |
| Drive ready time | 10 s |
| Internal | Yes |
| Quantity per box | 20 pc(s) |
| Acoustic pressure emissions | 2.4 dB |
