Samsung 400GB Ultra-ATA/133 HDD, 20-Pk
Model 400GB Ultra-ATA/133 HDD, 20-PkPart no. HD400LD?20PK
30 specifications
- Storage400 GB
- ConnectivityUltra-ATA/133
- Weight651 g
- Power consumption (typical)9.6 W
- Operating temperature (T-T)0 - 60 °C
- Width147 mm
Overview
- Storage
- 400 GB
- Connectivity
- Ultra-ATA/133
- Weight
- 651 g
- Power consumption (typical)
- 9.6 W
- Operating temperature (T-T)
- 0 - 60 °C
- Width
- 147 mm
- Brand
- Samsung
- Category
- Internal Hard Drive
- Model
- 400GB Ultra-ATA/133 HDD, 20-Pk
- Part number
- HD400LD?20PK
- Also known as
- Samsung Spinpoint T 400GB Ultra-ATA/133 HDD, 20-Pk internal hard drive 7200 RPM 8 MB 3.5" Ultra-ATA/133
Specifications
30 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| HDD capacity | 400 GB |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| Interface | Ultra-ATA/133 |
| Storage drive buffer size | 8 MB |
| Full stroke seek time | 18 ms |
| Track to track seek time | 0.8 ms |
| Average seek time | 8.9 ms |
| Average latency | 4.17 ms |
| Bytes per sector | 512 |
| Start/stop cycles | 50000 |
| Mean time between failures (MTBF) | 600000 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 9.6 W |
| Power consumption (standby) | 0.45 W |
| Operating voltage | 5 / 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating shock | 63 G |
| Non-operating shock | 300 G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 147 mm |
| Depth | 101.6 mm |
| Height | 26.1 mm |
| Weight | 651 g |
Other features
| Specification | Value |
|---|---|
| Power requirements | +5V; +12V |
| Drive device, transfer rate | 133 MB/s |
| Drive ready time | 10 s |
| Internal | Yes |
| Acoustic pressure emissions | 2.8 dB |
