StarTech.com 8 Port Serial Hub USB to RS232/RS485/RS422 Adapter - Industrial USB 2.0 to DB9 Serial Converter Hub - IP30 Rated - Din Rail Mountable Metal Serial

StarTech.com 8 Port Serial Hub USB to RS232/RS485/RS422 Adapter - Industrial USB 2.0 to DB9 Serial Converter Hub - IP30 Rated - Din Rail Mountable Metal Serial

Model ICUSB234858IEAN 065030878579

49 specifications
  • Weight688 g
  • ColourBlack
  • Ports quantity8
  • Housing materialSteel
  • Power source typeAC
  • Linux operating systems supportedYes
See all specifications

Overview

Weight
688 g
Colour
Black
Ports quantity
8
Housing material
Steel
Power source type
AC
Linux operating systems supported
Yes
Brand
StarTech.com
Model
ICUSB234858I
Part number
ICUSB234858I
EAN / UPC
065030878579
Also known as
StarTech.com 8 Port Serial Hub USB to RS232/RS485/RS422 Adapter - Industrial USB 2.0 to DB9 Serial Converter Hub - IP30 Rated - Din Rail Mountable Metal Serial

Specifications

49 specifications in 13 groups

Ports & interfaces

Ports quantity8
Host interfaceUSB 2.0
Hub interfacesSerial
USB 2.0 ports quantity2
RS-232 ports8
Card reader integratedNo
DC-in jackYes

Features

Housing materialSteel
Product colourBlack
Surge protectionYes
LED indicatorsPower

Power

Power source typeAC
Power consumption (typical)36 W
Input current1 A
Input voltage100 - 240 V
Output voltage12 V
Output current3 A
Power plug typeType M

System requirements

Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterpri
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Weight & dimensions

Width128 mm
Depth219 mm
Height25 mm
Weight688 g

Packaging data

Package width195 mm
Package depth294 mm
Package height70 mm
Package weight1.6 kg

Packaging content

AC adapter includedYes
Included power plug typesANZ, EU, UK, US
Cables includedUSB
DIN rail kit includedYes

Operational conditions

Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)-20 - 85 °C
Operating relative humidity (H-H)5 - 95%

Performance

Data bits7, 8
Stop bits1, 2
Parity bitEven, Mark, No, Odd, Space
Baud rate921.6 Kbit/s

Sustainability

Sustainability complianceYes

Logistics data

Master (outer) case width398 mm
Master (outer) case length514 mm
Master (outer) case height322 mm
Products per master (outer) case14 pc(s)
Harmonized System (HS) code84719000

Technical details

Compliance certificatesCE, RoHS

Other features

ChipsetFTDI - FT4232H, Genesys Logic - GL825
