j5create JCH453 USB4® 8K60 Slim Hub
j5create

JCH453 USB4® 8K60 Slim Hub

Model JCH453-NEAN 847626006548

41 specifications
  • Weight74 g
  • ColourGrey
  • Ports quantity5
  • Data transfer rate10000 Mbit/s
  • Input current5 A
  • Windows operating systems supportedYes
See all specifications

Overview

Weight
74 g
Colour
Grey
Ports quantity
5
Data transfer rate
10000 Mbit/s
Input current
5 A
Windows operating systems supported
Yes
Brand
j5create
Model
JCH453-N
Part number
JCH453-N
EAN / UPC
847626006548, 4712795087277
Also known as
j5create JCH453 USB4® 8K60 Slim Hub

Specifications

41 specifications in 8 groups

Ports & interfaces

Ports quantity5
Host interfaceUSB4
Hub interfacesHDMI, USB 3.2 Gen 2 (3.1 Gen 2) Type-A, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, USB Type-C
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity2
HDMI ports quantity1
HDMI version2.1
USB Type-C DisplayPort Alternate ModeYes

Features

Data transfer rate10000 Mbit/s
Supported graphics resolutions1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160, 7680 x 4320
Maximum resolution (HDMI)7680 x 4320 pixels
Housing materialAluminium
Product colourGrey
USB Power Delivery (USB PD)Yes
USB Power Delivery up to100 W
Number of displays supported1
Plug and PlayYes

Power

Input current5 A
Input voltage20 V
Output voltage20 V
Output current4.75 A
Power plug typeType C

System requirements

Windows operating systems supportedYes
Mac operating systems supportedYes
Other operating systems supportedChromeOS
Minimum system requirementsAvailable Thunderbolt™ 4, Thunderbolt™ 3, USB4®, and USB-C® host laptops. GPU and video source: DisplayPort™ 1.4 alt mode with DSC supports 8K 60 Hz or 4K 144Hz DisplayPort™ 1.4 alt mode without DSC supports 8K 30 Hz or 4K 120 Hz DSC = VESA® Display Stream Compression (DSC) Standard. Only available

Weight & dimensions

Width116.3 mm
Depth45 mm
Height11 mm
Weight74 g

Packaging data

Quantity per pack1 pc(s)
Package width189.9 mm
Package depth85 mm
Package height17.5 mm
Package weight138 g
Package typeBox

Packaging content

Packaging content1 - JCH453 USB4 8K60 Slim Hub 1 - Quick Installation Guide (QIG)

Operational conditions

Operating temperature (T-T)-1 - 41 °C
Storage temperature (T-T)-17 - 68 °C
Operating relative humidity (H-H)0 - 85%
Storage relative humidity (H-H)0 - 85%
