HG55ET690U 139.7 cm (55") 4K Ultra HD Smart TV Black 20 W
Model HG55ET690UPart no. HG55ET690UXXXUEAN 8806092210851
75 specifications
- Display139.7 cm (55")
- Resolution3840 x 2160 pixels
- Energy classG
- ColourBlack
- Smart TVYes
- HDMI ports quantity3
Overview
- Display
- 139.7 cm (55")
- Resolution
- 3840 x 2160 pixels
- Energy class
- G
- Colour
- Black
- Smart TV
- Yes
- HDMI ports quantity
- 3
- Brand
- Samsung
- Category
- Hospitality TV
- Model
- HG55ET690U
- Part number
- HG55ET690UXXXU
- EAN / UPC
- 8806092210851
- Also known as
- Samsung HG55ET690U 139.7 cm (55") 4K Ultra HD Smart TV Black 20 W
Specifications
75 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 139.7 cm (55") |
| HD type | 4K Ultra HD |
| Display resolution | 3840 x 2160 pixels |
| Display technology | LED |
| Screen shape | Flat |
| Supported graphics resolutions | 3840 x 2160 |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Picture processing technology | Samsung Contrast Enhancer |
| Smart modes | Movie, Natural |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 200 x 200 mm |
Performance
| Specification | Value |
|---|---|
| Smart TV | Yes |
| On Screen Display (OSD) | Yes |
| Electronic Programme Guide (EPG) | Yes |
| Auto power off | Yes |
| ConnectShare (HDD) | Yes |
| ConnectShare (USB) | Yes |
| Energy saving mode | Yes |
| Power on mode | Yes |
| Teletext function | Yes |
Hospitality features
| Specification | Value |
|---|---|
| Hospitality home menu | Yes |
| Hotel channel list | Yes |
| Hospitality Plug and Play | Yes |
| My Channel function | Yes |
| Multi-code remote control | Yes |
| Screwed battery cover | Yes |
| Music mode backlight on/off | Yes |
| Subtitles function | Yes |
| Auto source mode | Yes |
| Soundbar compatibility | Yes |
| Logo display with time-out setting (BMP/movie) | Yes |
| Alarm clock | Yes |
| Content management solution | Samsung LYNK REACH |
| LYNK REACH version | 4.0 |
| Security mode | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 3 |
| DVI port | Yes |
| USB 2.0 ports quantity | 2 |
| RF ports quantity | 2 |
Audio
| Specification | Value |
|---|---|
| Number of speakers | 2 |
| RMS rated power | 20 W |
| Audio decoders | Dolby Digital Plus |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 0.5 W |
| Power consumption (standby) | 150 W |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 102 kWh |
| Energy consumption (HDR) per 1000 hours | 141 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 40 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 1230.5 mm |
| Depth (with stand) | 226.5 mm |
| Height (with stand) | 759.8 mm |
| Weight (with stand) | 17.5 kg |
| Width (without stand) | 1230.5 mm |
| Depth (without stand) | 59.9 mm |
| Height (without stand) | 707.2 mm |
| Weight (without stand) | 17.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1467 mm |
| Package depth | 158 mm |
| Package height | 843 mm |
| Package weight | 22.8 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Remote control type | TM1240A |
| Cables included | AC |
| Mounting kit | Yes |
TV tuner
| Specification | Value |
|---|---|
| Tuner type | Analog |
| Auto channel search | Yes |
