External SSD
512GB NVMe M.2 3D TLC 80mm with C-C & C-A Cable
Model OSEC512NVMEEAN 5059902003461
46 specifications
- Storage512 GB
- ConnectivityPCI Express 3.0
- ColourAluminium, Grey
- USB connectorUSB Type-C
- Hardware encryptionNo
- Operating voltage3.3 V
Overview
- Storage
- 512 GB
- Connectivity
- PCI Express 3.0
- Colour
- Aluminium, Grey
- USB connector
- USB Type-C
- Hardware encryption
- No
- Operating voltage
- 3.3 V
- Brand
- Origin Storage
- Category
- External Solid State Drive
- Model
- OSEC512NVME
- Part number
- OSEC512NVME
- EAN / UPC
- 5059902003461
- Also known as
- Origin Storage External SSD 512GB NVMe M.2 3D TLC 80mm with C-C & C-A Cable
Specifications
46 specifications in 10 groups
Solid state drive
| Specification | Value |
|---|---|
| SSD capacity | 512 GB |
| SSD form factor | M.2 |
| Interface | PCI Express 3.0 |
| Memory type | 3D TLC |
| NVMe | Yes |
| Read speed | 1050 MB/s |
| Write speed | 1000 MB/s |
| Random read (4KB) | 179000 IOPS |
| Random write (4KB) | 102000 IOPS |
| Seek time | 0 ms |
| Access time | 0.2 ms |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connector | USB Type-C |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| Thunderbolt technology | No |
| Wi-Fi | No |
| Data transfer rate | 640 Gbit/s |
Features
| Specification | Value |
|---|---|
| Product colour | Aluminium, Grey |
| Housing material | Aluminium, Plastic |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mean time between failures (MTBF) | 1000000 h |
| Compliance certificates | RoHS |
Security
| Specification | Value |
|---|---|
| Hardware encryption | No |
| Password protection | No |
| TRIM support | Yes |
| S.M.A.R.T. support | Yes |
Power
| Specification | Value |
|---|---|
| Operating voltage | 3.3 V |
| Power consumption (idle) | 0.47 W |
| Power consumption (read) | 2.84 W |
| Power consumption (write) | 3.22 W |
| Power consumption (average) | 3.03 W |
| Power consumption (max) | 3.22 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -45 - 105 °C |
| Operating relative humidity (H-H) | 5 - 98% |
| Storage relative humidity (H-H) | 5 - 98% |
| Operating shock | 1500 G |
| Operating vibration | 16 G |
| Maximum operating altitude | 36576 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 117.5 mm |
| Depth | 13.5 mm |
| Height | 40 mm |
Packaging data
| Specification | Value |
|---|---|
| Package type | Blister |
Other features
| Specification | Value |
|---|---|
| TBW rating | 100 |
| Warranty period | 5 year(s) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717070 |
