VPC25-W53-P1 embedded computer
2 GHz 256 GB SSD 16 GB
Model VPC25-W53-P1EAN 766907011982
47 specifications
- Memory16 GB
- Storage256 GB
- Weight1.95 kg
- Processor frequency2 GHz
- Wi-FiYes
- USB 2.0 ports quantity2
Overview
- Memory
- 16 GB
- Storage
- 256 GB
- Weight
- 1.95 kg
- Processor frequency
- 2 GHz
- Wi-Fi
- Yes
- USB 2.0 ports quantity
- 2
- Brand
- Viewsonic
- Category
- Embedded Computer
- Model
- VPC25-W53-P1
- Part number
- VPC25-W53-P1
- EAN / UPC
- 766907011982
- Also known as
- Viewsonic VPC25-W53-P1 embedded computer 2 GHz 256 GB SSD 16 GB
Specifications
47 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 2 GHz |
| Processor manufacturer | Intel |
| Processor cores | 6 |
| Processor boost frequency | 3.6 GHz |
| Processor cache | 12 MB |
| System bus rate | 8 GT/s |
| Processor threads | 12 |
| PCI Express slots version | 3.0 |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor codename | Comet Lake |
| Thermal Design Power (TDP) | 35 W |
| Configurable TDP-up frequency | 1.3 GHz |
| Configurable TDP-down | 25 W |
| PCI Express configurations | 1x8+2x4, 1x16, 2x8 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 16 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| HDD interface | SATA III |
| SSD interface | PCI Express |
| SSD capacity | 256 GB |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
Power
| Specification | Value |
|---|---|
| Power supply input voltage | 110 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 246 mm |
| Depth | 32.2 mm |
| Height | 263.4 mm |
| Weight | 1.95 kg |
| Package width | 350 mm |
| Package depth | 90 mm |
| Package height | 310 mm |
| Package weight | 2.1 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84713000 |
