VPC12-WPO-17 embedded computer
2.4 GHz Intel® Core™ i5 256 GB SSD 8 GB
Model VPC12-WPO-17EAN 766907019421
60 specifications
- ProcessorIntel® Core™ i5
- Memory8 GB
- Storage256 GB
- OSFreeDOS
- Weight800 g
- ColourBlack
Overview
- Processor
- Intel® Core™ i5
- Memory
- 8 GB
- Storage
- 256 GB
- OS
- FreeDOS
- Weight
- 800 g
- Colour
- Black
- Brand
- Viewsonic
- Category
- Embedded Computer
- Model
- VPC12-WPO-17
- Part number
- VPC12-WPO-17
- EAN / UPC
- 766907019421
- Also known as
- Viewsonic VPC12-WPO-17 embedded computer 2.4 GHz Intel® Core™ i5 256 GB SSD 8 GB
Specifications
60 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 2.4 GHz |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor generation | 8th gen Intel® Core™ i5 |
| Processor model | i5-8279U |
| Processor cores | 4 |
| Processor boost frequency | 4.1 GHz |
| Processor cache | 6 MB |
| Processor cache type | Smart Cache |
| Processor threads | 8 |
| Thermal Design Power (TDP) | 28 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| SSD interface | SATA III |
| SSD capacity | 256 GB |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Plus Graphics 655 |
| On-board graphics card family | Intel Iris Plus Graphics |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card burst frequency | 1150 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3EA5 |
| On-board graphics card 4K support | Yes |
| Discrete graphics card | No |
| Graphics card Open GL support | Yes |
| Number of displays supported | 3 |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Bluetooth | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Bluetooth version | 4.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-out | Yes |
| Microphone in | Yes |
| DC-in jack | Yes |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | FreeDOS |
Power
| Specification | Value |
|---|---|
| DC input voltage | 12/19 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Certificates
| Specification | Value |
|---|---|
| Certification | CE EMC, CE LVD, CE RED, RoHS, WEEE, BIS, WPC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 202 mm |
| Depth | 30 mm |
| Height | 119 mm |
| Weight | 800 g |
| Package width | 254 mm |
| Package depth | 77 mm |
| Package height | 196 mm |
| Package weight | 1.1 kg |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
