OPS-Kbl-i7v-d8/128/W10IoT/TPM B
Model OPS-Kbl-i7v-d8/128/W10IoT/TPM BPart no. 100015864EAN 4260400615532
47 specifications
- ProcessorIntel® Core™ i7
- Memory32 GB
- Storage128 GB
- Weight800 g
- ColourBlack
- Processor frequency3 GHz
Overview
- Processor
- Intel® Core™ i7
- Memory
- 32 GB
- Storage
- 128 GB
- Weight
- 800 g
- Colour
- Black
- Processor frequency
- 3 GHz
- Brand
- NEC
- Category
- Embedded Computer
- Model
- OPS-Kbl-i7v-d8/128/W10IoT/TPM B
- Part number
- 100015864
- EAN / UPC
- 4260400615532
- Also known as
- NEC OPS-Kbl-i7v-d8/128/W10IoT/TPM B 3 GHz Intel® Core™ i7 128 GB SSD 32 GB
Specifications
47 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor frequency | 3 GHz |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 7th gen Intel® Core™ i7 |
| Processor model | i7-7820EQ |
| Processor cores | 4 |
| Processor boost frequency | 3.7 GHz |
| Processor cache | 8 MB |
| Processor threads | 8 |
| Processor lithography | 14 nm |
| Thermal Design Power (TDP) | 45 W |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 2x SO-DIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 128 GB |
| Storage media | SSD |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| SSD interface | M.2 |
| SSD capacity | 128 GB |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics 630 |
| Discrete graphics card | No |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
Performance
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 8 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 120 mm |
| Depth | 190 mm |
| Height | 30 mm |
| Weight | 800 g |
| Package width | 190 mm |
| Package depth | 70 mm |
| Package height | 260 mm |
| Package weight | 900 g |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
